Rated Capacity : 1,000GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
Form Factor : M.2 (2280)
Interface : PCIe® 5.0 x4, NVMe™ 2.0
Dimension (WxHxD) : Max 80.15 x Max 22.15 x Max 2.38 mm
Weight : Max 9.0g Weight
Storage Memory : Samsung V-NAND TLC
Controller : Samsung in-house Controller
Cache Memory : Samsung 1GB Low Power DDR4X SDRAM
TRIM Support : Supported
S.M.A.R.T Support : Supported
GC (Garbage Collection) : Auto Garbage Collection Algorithm
Sequential Read : Up to 14,700 MB/s * Performance may vary based on system hardware & configuration
Sequential Write : Up to 13,300 MB/s * Performance may vary based on system hardware & configuration
Random Read : Up to 1,850,000 IOPS * Performance may vary based on system hardware & configuration
Random Write : Up to 2,600,000 IOPS * Performance may vary based on system hardware & configuration
Average Power Consumption (system level) : Average: Read 7.6 W / Write 7.2 W* Actual power consumption may vary depending on system hardware & configuration
Power consumption (Idle) : Typical 4 mW * Actual power consumption may vary depending on system hardware & configuration
Power Consumption (Device Sleep) : Typical 3.3 mW * Actual power consumption may vary depending on system hardware & configuration
Allowable Voltage : 3.3 V ± 5 % Allowable voltage
Reliability (MTBF) : 1.5 Million Hours Reliability (MTBF)
Operating Temperature : 0 - 70 ℃ Operating Temperature
Shock : 1,500 G & 0.5 ms (Half sine)
Installation Kit : Not Available
Management SW : Magician Software for SSD management
Warranty : 5-year Limited Warranty or 600TBW Limited Warranty
