About the Product
Top features
Product Series |
Harmony XAC |
|
Product Type or component |
Contact block |
|
Component name |
XENG |
|
Electric circuit type |
Control Circuit |
|
Application Block contacts |
2 speeds |
|
Contact Block Type |
Single |
|
Type operator |
Spring return |
|
Product compatibility |
XACA XACA9. .. head |
|
Type and composition of contacts |
1 NC + 2 NA |
|
Mounting Block |
Front mount |
|
Contact Performance |
Break slow Stair step |
Additional features
Junction-terminals |
Screw terminals, 1x0.5. 1x2.5 mm² without terminal Screw terminals, 1x0.5. 2x1.5 mm² with terminal |
|
Mechanical durability |
1000000 cycles |
|
Code designation of contacts |
A600 AC-15, EU = 240 V, Ie = 3 A according to IEC 60947-5-1 appendix a A600 AC-15, EU = 600 V, Ie = 1,2 A according to IEC 60947-5-1 appendix a Q600 DC-13, EU = 250 V, Ie = 0,27 A according to IEC 60947-5-1 appendix a Q600 DC-13, EU = 600 V, Ie = 0,1 A according to IEC 60947-5-1 appendix a |
|
[Ithe] Conventional thermal intensity in the envelope |
10 A |
|
[Ui] rated insulation voltage |
600 V (pollution Grade 3) according to En> 40 a |
|
[Uimp] Voltage surge resistance |
6 kV according to En> 40 a |
|
Maximum Resistance Across Terminals |
25 MOhm |
|
Operating Force |
18 N |
|
Short circuit protection |
10 A fuse protection by fusi type gG cartridge |
|
Rated operating power in W |
40 W DC-13 for 1000000 cycles, function rate <60 cycles/mn in 120 V,
Charging factor = 0,5-cable type: inductive charging) according to IEC 60947-5-1 Annex C
48 W DC-13 for 1000000 cycles, function rate <60 cycles/mn in 48 V, Charging factor = 0,5-cable type: inductive charging) according to IEC 60947-5-1 Annex C
65 W DC-13 for 1000000 cycles, function rate <60 cycles/mn in 24 V, Charging factor = 0,5-cable type: inductive charging) according to IEC 60947-5-1 Annex C
|
|
Description iso terminals No 1 |
(21-22)NC (33-34)NO_CL (13-14)NO |
|
Product Weight |
0,04 kg |
